The water block is filled with a myriad of ARGB shimmering shining stars. This lighting effect, referred to as ”Nebula”, will provide your build with the most stunning visual aesthetics. The lighting effects can be synced with an ARGB motherboard. Gaze into the realms of Nebula!
High static pressure ARGB fan Luna AL120 is tailor-made for liquid-cooling, providing powerful cooling performances while reflecting ARGB lighting through its crescent white fan blades.
Learn More
The powerful pump has been specially designed to cushion vibrations and suppress noise pollution.
High-density microchannel fins and large heat dispatching area on the radiator ensure excellent heat conducting efficiency.
The water block is compatible with all the latest Intel and AMD CPU sockets and features user-friendly tools for simple and quick installation.
The lighting effects can be synced with an addressable motherboard or controlled via the provided ARGB One-Click Controller.
* The addressable cable can only be used with motherboards with an ADD_HEADER (3-pin, 5V).
The tubing is sleeved with braided nylon for added protection.
| Model | NR36 | |
|---|---|---|
| Model Number | IW-LC-NR36 | |
| CPU Socket Support | Intel® LGA 1851/ 1700/ 1200/ 2066/ 2011-V3/ 2011/ 1366/ 1156/ 1155/ 1151/ 1150 AMD® AM5/ AM4/ AM3+/ AM3/ AM2+/ AM2/ FM2+/ FM2/ FM1/ TR4 |
|
| Radiator | Dimensions (L x W x H) |
397 x 120 x 27 mm (15.6 x 4.7 x 1.1") |
| Materials | Aluminium | |
| Tube Length | 450 mm | |
| Tube Materials | Rubber with Nylon Braided Sleeve | |
| Water Block | Dimensions (L x W x H) |
87.3 x 75 x 68 mm (3.4 x 3.0 x 2.7") |
| Materials | Copper, Glass, Plastic | |
| Pump | Dimensions (L x W x H) |
66 x 50 x 31 mm (2.6 x 2.0 x 1.2") |
| Materials | PPS GF | |
| Pump Speed | 5200 RPM +/- 10% | |
| Fans | Model | Luna Series AL120 |
| Quantity Included | 3 PCS | |
| Dimensions (L x W x H) |
120 x 120 x 25 mm (4.7 x 4.7 x 1.0") |
|
| Speed Mode | PWM 600 - 1800 +/- 10% RPM | |
| Noise Level | 25 dB(A) (Normal) | |
| Airflow | 82.96 CFM | |
| Air Pressure | 2.31 mm / H2O | |
| Connectors | 4-Pin (12V, PWM), 3-Pin (5V, ARGB) | |
| Bearing Type | Long Lifespan Sleeve Bearing | |
| Package Contents | 1 x InWin NR Series 360 mm CPU Liquid Cooler | |
| 3 x InWin AL120 Addressable Fans | ||
| ARGB One-Click Controller | ||
| Fan and Radiator Mounting Screws Pack | ||
| Mounting Kit for CPU Sockets | ||
| Cable Pack | ||
| Package Dimensions (L x W x H) |
459 x 244 x 136 mm (18.1 x 9.6 x 5.4") |
|
| Net Weight | 1.05 kg / 2.31 lb | |
| Gross Weight | 2.45 kg / 5.4 lb | |
| Warranty | 3 Years | |
| * InWin's products comply with RoHS regulation. * Specifications may vary based on different regions. |
||
