A1 Plus

A1 PLUS: Feel its Appeal

Addressable RGB Lighting

Sirius Loop ASL120 Fans Included

650W PSU 80 PLUS GOLD

Qi 1.2 10W Charging Panel

Expression Through Lights

Personalize your rig with addressable RGB modes! The A1 PLUS features a tinted transparent stand and the addressable RGB lights pierce through to create an awesome lighting experience.

Loop in More Color!

The A1 PLUS comes with two complementary Sirius Loop ASL120 fans. The matte black structure is fitted with dual radiant addressable RGB loops. The circular RGB outline is presented on both sides of the fan so lighting is present no matter the fan placement.

Learn More

*Included RGB controller allows fans to light up without an addressable RGB motherboard.

*Please make sure your motherboard supports addressable RGB lighting.

InWin 650W PSU

The InWin 650W PSU is 80 PLUS Gold certified. The PSU is prebuilt within the A1 PLUS with the cables already managed and is accommodated with two GPU connectors (PCI-E 6+2-pin) for high-end graphics cards.

5V and 3.3V DC to DC Design

The DC to DC converter design provides superior dynamic response and supports a foundation for greater system stability.

5-Year Warranty

InWin offers a 5-year warranty to back our claim of providing reliable and dependable performance.

InWin 650W PSU

5V and 3.3V DC to DC Design

5-Year Warranty

Top Panel Wireless Charger

The A1 PLUS's convenient top wireless charging station is now compatible with WPC Qi 1.2. It now emits 10W of power to strengthen the charging capacity to Qi enabled mobile devices and gaming mice.

Squaring Infinite Possibilities

The square structure provides a hassle-free installation, and the capacity to house powerful hardware in its Mini-ITX form. The A1 PLUS supports a CPU heatsink height up to 160mm and accommodates up to 320mm length graphics cards.

Specifications

Model A1 PLUS
Part Number IW-A1PLUS-BLACK, IW-A1PLUS-WHITE
Colors Black, White
Case Type Mini ITX Tower
Case Materials SECC, Tempered Glass
M/B Compatibility Mini-ITX
Expansion Slots PCI-E x 2
Maximum Compatibility VGA Card Length: 320mm
CPU Heatsink Height: 160mm
Front Ports 2 x USB 3.0
HD Audio
Internal Drive Bays 2 x 2.5"
Thermal Solution Compatibility 1 x 120mm Side Fan
1 x 120mm Rear Fan / 120mm Radiator
2 x 120mm Bottom Fan
Power Supply Compatibility InWin 650W PSU Included
AC Input/Efficient AC input: 100-240V / 80 PLUS Gold
Product Dimensions
(H x W x D)
with Screw & Handle Height

273 x 224 x 357mm
10.7" x 8.8" x 14.1"

Product Dimensions
(H x W x D)
231 x 210 x 343mm
Package Dimensions
(H x W x D)

344 x 295 x 414mm
13.5" x 11.6" x 16.2"

Net Weight 7.1 kg/ 15.7lbs
Gross Weight 7.9 kg/ 17.5lbs
* InWin retail PC chassis & case fans feature a 2-years limited warranty.
* Gold Series PSU features a 5-years limited warranty.
* The wireless Qi charger features a 1-year limited warranty.
* InWin products comply with RoHS regulation.
* Specifications may vary based on different regions.
Model
AC INPUT 100-240Vac, 10A, 47-63Hz
DC OUTPUT +12V +5V +3.3V -12V +5VSB Total Power
IW-GD650PS
Max. Output Current 54A 20A 20A 0.3A 2.5A 650W
Max. Combined Power
648W
100W
3.6W
12.5W
